Aventon Pace 500 ST Next-Gen

  • Sale
  • Regular price $1,599.99
Shipping calculated at checkout.


Overview

The Next-Gen Pace 500 Step-Through makes getting on the ebike easy. The powerful 500W motor ensures that, even on steep hills, your ebike will get you to the top, and with its improved, fully integrated battery, you still have juice left to get home. Newly added integrated tail and headlight will ensure you will see and be seen on your journies ahead whether its a trip to the farmers market or a casual stroll in the park.

Size and Fit

The Pace 500 Step-Through comes in 2 sizes to suit most adults.

S/M: 5'1" - 5'11"

M/L: 5'11" - 6'4"

Frame Size S/M M/L
Height 5'1" - 5'11" 5'11" - 6'4"
Top Tube Length 617mm 639mm
Reach 349mm 363mm
Head Tube Length 195mm 215mm
Standover Height 425mm 445mm
Wheelbase 1086mm 1108mm
Min Saddle Height 765mm 805mm
Max Saddle Height 965mm 995mm



Specs

MOTOR
48V, 500w Brushless Rear Hub Motor
THROTTLE
Thumb Throttle on Handlebars
DISPLAY
LCD Smart Easy Read Display with Backlight, Colorful screen with app
SPEED
Up to 28 MPH on Pedal Assist
BATTERY
Removable Internal Lithium-ion 48V, 12.8Ah(614Wh) with LG Cells
SENSORS
Cadence Sensor, Speed Sensor
PEDAL ASSIST
5 Levels
CHARGER
48V 3 Amp Fast Charger, 4-5 Hour Charging
RANGE
25-48 Miles Average
FRAME
6061 Single-Butted Aluminum Alloy with Internal Battery
WEIGHT
52lbs
PEDALS
9/16" Alloy Platform
WEIGHT LIMIT
Maximum Payload Capacity: 300 lbs
FORK
AE-E08 PACE V2 AL fork
BOTTOM BRACKET
Square Taper, Sealed
CRANKSET
170mm w/46T
BRAKES
Hydraulic Disc Brakes
REAR DERAILLEUR
8 Speed
CASSETTE
12-32T, 8 Speed
SHIFT LEVER
8 Speed Trigger
CHAIN
8 Speed
RIM
Double Wall Aluminum 36h Front & Rear
SPOKES
Black Stainless 13 Gauge Front/12 Rear
TUBES
Butyl Rubber, Schrader Valve 27.5x2.2
HUBS
36H Disc Nutted Front and Rear
TIRES
27.5x2.2" Ebike Rated, Reflective Sidewalls
SADDLE
Aventon by SelleRoyal
SEATPOST
Forged Alloy, 30.9mm, 2-Bolt Clamp
HEADSET
VP Sealed Bearing Headset
SEAT CLAMP
Quick Release
HANDLEBARS
Aluminum 31.8 15 Degree Sweptback
GRIPS
Ergonomic Comfort
STEM
Threadless, Adjustable 31.8mm
